M3-TR9 Radio Module

SKU: YM7900 Categories: ,

Description

SATELLINE-M3-TR9 is a 900 MHz ISM data radio transceiver module in a lightweight single PCB. It features compatibility with Freewave and Intuicom spread-spectrum radios, offering 115.2kbps speeds over the air. This small size, light weight, robust module can be integrated into OEM products, and can withstand a wide temperature range of -40 to +70 C.

Additional information

Frequency Range

902 to 928 MHz

Hopping Bands

7 (user selectable)

Hopping Patterns

15 per band, 105 total (user selectable)

Hopping Channels

50-112 (user selectable)

Carrier Power

1000mW

Receiver Sensitvity

-109 dBm

Data Interface Speed

up to 115.2kbps

Electrical Interface

CMOS / UART

Packet Throughput

115.2 kbps

Interface Connector

1.27 mm pitch socket

Antenna Connector

HIROSE U.FL compatible type (adapter cables available for TNC, SMA, MCX, MMCX etc.)

Operating Voltage

3.5 to 5.5 VDC

Power Consumption

0.4W RX, 3.3W TX @ 1W output power

Operating Temperature Range

-40 to +70 C

Size (H x W x D)

57 x 36 x 6.7 mm

Weight

20g
